技術規格
|
型號
|
|||||
|
XJP-403J
|
XJP-403JT
|
XJP-403JA
|
XJP-403JAT
|
|||
|
觀察頭
|
45 度鉸鏈式雙目頭 ( 50mm -75mm )
|
●
|
|
●
|
|
|
|
45 度鉸鏈式三目頭 ( 50mm -75mm )
|
|
●
|
|
●
|
||
|
目鏡
|
WF10X /20mm
|
●
|
●
|
|
|
|
|
WF10X /22mm
|
|
|
●
|
●
|
||
|
WF10X / 20mm 帶十字分劃板及0.1mm 刻尺
|
●
|
●
|
●
|
●
|
||
|
轉換器
|
四孔轉換器
|
|
|
●
|
●
|
|
|
五孔轉換器
|
●
|
●
|
|
|
||
|
物鏡
|
195 金相物鏡
|
4 X /0.1W.D .25mm
|
●
|
●
|
|
|
|
10 X /0.25W.D .11mm
|
||||||
|
20 X /0.4W.D .9mm
|
||||||
|
40 X /0.6W.D. 3.8mm
|
||||||
|
無限遠金相物鏡
|
4 X /0.1W.D .25mm
|
|
|
●
|
●
|
|
|
10 X / 0.25W.D .12mm
|
||||||
|
20 X / 0.4W.D .10mm
|
||||||
|
40 X / 0.6W.D. 7.1mm
|
||||||
|
50 X /0.75W.D. 1.9mm 80 X (S) /0.9W.D. 0.9mm
|
○
|
○
|
○
|
○
|
||
|
平臺
|
雙層移動平臺
|
●
|
●
|
●
|
●
|
|
|
平臺尺寸 : 242mm × 172mm
|
||||||
|
中心載物臺:Φ110mm
|
||||||
|
移動范圍 : 75mm × 50mm
|
||||||
|
調焦
|
粗、微動同軸調焦，采用齒輪變速箱調焦機構，微動格值0.002mm
|
●
|
●
|
●
|
●
|
|
|
照明
|
落射柯勒照明，帶孔徑可變光欄和視場可變光欄
12V/30W.AC85V-230V 光源可調節
|
●
|
●
|
●
|
●
|
|
|
偏光裝置
|
檢偏鏡可 360 度轉動，起偏鏡檢偏鏡均可移出光路
|
●
|
●
|
●
|
●
|
|
|
濾色片
|
藍色、綠色、黃色
|
●
|
●
|
●
|
●
|
|
|
檢測工具
|
0.01mm 測微尺
|
●
|
●
|
●
|
●
|
|
|
可供附件
|
130 萬、200萬、300 萬、500萬像素 CMOS電子目鏡
|
|||||
|
攝影裝置
|
||||||
